Jet 354551 J-A5818 15″ Variable Speed Floor Model Drill Press 230/460V

These JET Drill Presses use a variable-speed motor with the stepped-pulley system, and come equipped with a continuously variable transmission. This enables use at a wide range of speeds, as well as the ability to change speed during operation. A scale-marked hand wheel that matches the desired machine speed is mounted to a reduction gearing system for precise operator control. This adjusts the gearing ratio between the motor’s fixed pulley and the output shaft’s variable pulley, changing the speed of the chuck. A tensioner pulley is implemented in the belt transmission to take up or release the slack in the belt as the speed changes.

• Full bearing support on quill for maximum spindle stiffness
• Handwheel speed adjustment of 400 to 5,000 RPM
• Large 2-1/4″ quill for greater accuracy
• 3″ column diameter for maximum head support
• 6″ stroke for deep hole application
• Accurate depth stop for precice hole depths
• 1/2″ drill chuck and arbor included
• Safety collar
